XR-Aluma-Pro Lite family breakdown
Return to the full air/water family lookup.
Open support page
MIG spool gun support
XR-Aluma-Pro Lite air-cooled parts lookup for the XR-Aluma-Pro Lite push-pull gun family. Stock numbers: 300948. Rated output: 175 A at 60% duty cycle. Wire range:.030 -.047 in. (0.8 - 1.2 mm) aluminum wire. Use the diagram and parts table to identify XR consumables before ordering.
As an Amazon Associate, I earn from qualifying purchases.
| Item # | Part # | Description | Qty | Buy |
|---|---|---|---|---|
| Gun | 300948 |
XR-Aluma-Pro Lite air-cooled, 25 ft. (7.6 m), 175 A at 60% duty cycle
|
1 | N/A |
254477 |
Head Tube Assembly, Aluma-Pro Lite (including)
|
1 | Amazon link: Needs verification. | |
| 1 | QT2-45 |
Tube, Body 45 Degree x 2.69 Lg
|
1 | Amazon link: Needs verification. |
1840057 |
Clip-on Q-Nut Cover
|
1 | Amazon link: Needs verification. | |
1840031 |
Body Tube Insulating Sleeve
|
2 | Amazon link: Needs verification. | |
| 2 | 4323R |
Insulator, Nozzle (Small)
|
1 | Amazon link: Needs verification. |
| 3 | DS-1 |
Diffuser, C-Fire (Small Nozzle)
|
1 | Amazon link: Needs verification. |
| 4 | NS-1218C |
Nozzle, C-Fire Small Copper 1/2 in. Recess 1/8 in.
|
1 | Amazon link: Needs verification. |
| 5 | T-047AL |
Centerfire Contact Tip, Aluminum 3/64 in.
|
1 | Amazon link: Needs verification. |
| 5 | T-035AL |
Centerfire Contact Tip, Aluminum .035
|
1 | Amazon link: Needs verification. |
| 6 | 258541 |
Kit, Jump Liner Assembly .030-.035 (5 pk)
|
1 | View on Amazon |
| 6 | 258542 |
Kit, Jump Liner Assembly .047-.062 (5 pk)
|
1 | View on Amazon |
| 6 | 258726 |
Kit, Jump Liner Assembly .030-.035 14 in. Long (5 pk)
|
1 | Amazon link: Needs verification. |
| 6 | 258727 |
Kit, Jump Liner Assembly .047-.062 14 in. Long (5 pk)
|
1 | Amazon link: Needs verification. |
M1440 |
Cable Liner for Gun
|
1 | View on Amazon | |
254756 |
Drive Roll
|
1 | Amazon link: Needs verification. | |
227439 |
Idler
|
1 | View on Amazon |
